• Two entrance both manned by trained security personal 24 x 7 working

• Facade Maintenance - Window Cleaning System

• Roadways & surface parking concrete paving in main drive way and drop off Grasscrete and interlocked concrete precast pavers in other areas Parking
• Pole mounted fixtures and custom designed granite finished bollard lighting
• Feature lighting of facade with fixtures concealed with in land-scaped and other areas

• 4 No's
• 16 passenger
• MITSUBISHI make
• 1.75 m/sec speed + 1 No. 1 service lift

• Plot Area - 56192 sq.ft.
• Shape of the Plot - Rectangular
• Frontage of the Plot - 198 ft.
• Plot Coverage - 44%

• umber of Floors: Basement + Ground + 7 Floor

• Super Built-up - 29500 sq.ft.
• Carpet- 22420 sq.ft.
• Floor to Ceiling : 3.40 m
• Floor to Floor : 4.0 m
• Typical Floor : 3.40 m
• Total Height: 34 m
• No. Of basement: 1
• Usage of Basements- Parking + Services

External Cladding

• Titanium blue reflective class
• Laminated reflective glass structural glazing for better noise control

Flooring

• Lantium - Granite
• Entrance & lift lobbies - Granite
• Tenant floor finish - 75 mm clearance left
• Passenger lift cabin - SS panels, Granite flooring,mirror
• Toilets - Floors & walls in ceramic tiles
• Entrance Lobby - Granite cladding / veneer on walls with architectural false ceiling

• 2,00,000 ltrs. sump OHWT Hydo Pneumatic system
• 70,000 ltrs OHWT

• H.T- HT power from TNEB
• Transformer- 2 x 1250 KVA
• Common DG- 100% power backup
• STP - 250 KLD Total Capacity Installed- 2500 KVA
• No. of Transformers Installed- 2 No's of 2.0 MVA dry type
• Power Allotted Per Floor- 240 KVA per floor

• Staircase - One Main staircase finished with granite and SS Handrail
• 2 Nos. of Fire escape Staircase Finished Kota stones with MS Handrail

• Provided at Ground level as per NBC norms.
• Wet riser / Hose reels adjacent to each staircase

• Tap off connections provided above the False ceiling installations to be done by the Tenant.
• Monitor module integrated with Building Fire alarm system

• 2 Nos. Electrical and 1 No. Diesel and 1 No. Jockey Pump
• Dedicated UG Sump - 2 lakh ltrs. capacity for Firefighting system.

• 2 lakh ltrs. UG sump with hydro pneumatic system.

• 70000 ltrs. Overhead water tank

• Power supply - 11 KV HT power supply from T.N.E.B.
• Power allotted per Floor - 240 KVA per Floor
• Total capacity installed - 3000 KVA

• 2 X 2000 KVA 'Dry type'

• 625 KVA - 1 No.

• 300 KLD

• 4 Nos of 'Mitsubishi' Elevators of 16 passengers capacity each and speed of 1.75 Mtr. per second.
• 1 No. of Service lift of 'Mitsubishi' Make of 20 passengers capacity and speed of 1.75 Mtr. per second.

• Parking:- 1 car park for every 1000 sq.ft.

• All Entrances and Exit points of the building manned by trained Personnel and 24 x 7 security.

• Window cleaning system and facility management Agency

• Roadways & Surface parking
• Concrete paving in main drive way and drop of Grasscrete and interlocked concrete precast pavers in other areas parking.

• Pole mounted fixtures and custom designed granite finished bollard lighting.

• Feature lighting of facade with fixtures concealed with landscape and other areas.

• Granite paving in different Finishes on Plaza and atrium
